Joma/Vinkelbeslag 2,5 mm/Angle bracket 423

Angle bracket 423

Used for cross joints timber to timber and timber to concrete.

The angle bracket are for light and medium duty connections.

Material

2,5 mm pre-galvanized steel plate

Spikhål: Ø 5,0 mm Bulthål: Ø 11,0 mm or Ø 13,0 mm Spår: (4230203): 14,0 x 20,0 mm

Artikelnr.	Tjocklek	Längd	Höjd	Bredd	Vikt
4230101	2,5	50	125	70	0,21	DWG 3D Step
4230201	2,5	100	155	80	0,35	DWG 3D Step
4230202	2,5	160	155	80	0,45	DWG 3D Step
4230203	2,5	60	175	75	0,30	DWG 3D Step
